Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
40.26ft in
C
Shipping Height Of Unit
12.6ft in
I
Max Cutting Height
34.65ft in
J
Max Loading Height
23.36ft in
K
Max Reach Along Ground
35.9ft in
L
Max Vertical Wall Digging Depth
19.56ft in
M
Max Digging Depth
22.48ft in
Boom/Stick Option (Hex) 1
Boom - 7060 mm, 23.2 ft in / Arm - 2400 mm, 7.10 ft in
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
40.03ft in
I
Max Cutting Height
34.55ft in
C
Shipping Height Of Unit
12.37ft in
J
Max Loading Height
23.56ft in
K
Max Reach Along Ground
37.21ft in
L
Max Vertical Wall Digging Depth
19.46ft in
M
Max Digging Depth
24.12ft in
Boom/Stick Option (Hex) 2
Boom - 7060 mm, 23.2 ft in / Arm - 2900 mm, 9.6 ft in
Boom/Stick Option (Hex) 3
A
Shipping Length Of Unit
39.57ft in
I
Max Cutting Height
36.03ft in
J
Max Loading Height
25ft in
C
Shipping Height Of Unit
12.24ft in
K
Max Reach Along Ground
39.05ft in
L
Max Vertical Wall Digging Depth
21.63ft in
M
Max Digging Depth
25.63ft in
Boom/Stick Option (Hex) 3
Boom - 7060 mm, 23.2 ft in / Arm - 3380 mm, 11.1 ft in
Boom/Stick Option (Hex) 4
A
Shipping Length Of Unit
39.51ft in
C
Shipping Height Of Unit
13.26ft in
I
Max Cutting Height
36.78ft in
J
Max Loading Height
25.66ft in
K
Max Reach Along Ground
40.92ft in
M
Max Digging Depth
27.73ft in
Boom/Stick Option (Hex) 4
Boom - 7060 mm, 23.2 ft in / Arm - 4000 mm, 13.1 ft in
Max Vertical Wall Dig Depth
23.53ft in
Boom/Stick Option (Hex) 5
A
Shipping Length Of Unit
38.62ft in
C
Shipping Height Of Unit
13.23ft in
I
Max Cutting Height
33.37ft in
J
Max Loading Height
22.15ft in
K
Max Reach Along Ground
34.03ft in
M
Max Digging Depth
20.9ft in
Boom/Stick Option (Hex) 5
Boom - 6550 mm, 21.6 ft in / Arm - 2400 mm, 7.10 ft in
Max Vertical Wall Dig Depth
17.72ft in
Boom/Stick Option (Hex) 6
I
Max Cutting Height
45.41ft in
J
Max Loading Height
34.26ft in
A
Shipping Length Of Unit
44.82ft in
K
Max Reach Along Ground
53.15ft in
C
Shipping Height Of Unit
17.07ft in
M
Max Digging Depth
37.93ft in
Boom/Stick Option (Hex) 6
Boom - 9000 mm, 29.6 ft in / Arm - 5850 mm, 19.2 ft in
Max Vertical Wall Dig Depth
33.86ft in
Dimensions
E
Ground Clearance
1.83ft in
G
Height To Top Of Cab
10.47ft in
B
Width To Outside Of Tracks
9.78ft in
D
Length Of Track On Ground
17.92ft in
H
Tail Swing Radius
12.31ft in
Removal Counterweight Clearance
4.25ft in
Undercarriage
F
Track Gauge
8.99ft in
N
Shoe Size
23.63in
Number Of Carrier Rollers Per Side
2
Drawbar Pull
8479999.43lb
Number Of Track Rollers Per Side
9
Number Of Shoes Per Side
53
Ground Pressure
11.8psi
Specifications
Engine
Number Of Cylinders
6
Engine Make
Cummins
Engine Model
QSM11
Net Power
342hp
Gross Power
357hp
Power Measured @
1900rpm
Max Torque
1235lb ft
Displacement
659cu in
Aspiration
Turbocharged
Torque Measured @
1400rpm
Operational
Operating Weight
106042.4lb
Fuel Capacity
164.1gal
Cooling System Fluid Capacity
13.3gal
Hydraulic System Fluid Capacity
100.4gal
Operating Voltage
24V
Engine Oil Capacity
10.1gal
Swing Drive Fluid Capacity
1.4gal
Alternator Supplied Amperage
70amps
Hydraulic Pump Flow Capacity
190.3gal/min
Swing Mechanism
Swing Speed
9rpm
